Aurora PANA X6 Automated Nucleic Acid Extraction System integrates multiple functional modules, including sample loading, sample pooling, nucleic acid extraction, PCR setup, reagent storage and a reserved PCR amplification module.
ChinaProduct Rating
This product has not been rated yet.
Aurora PANA X6 Automated Nucleic Acid Extraction System integrates multiple functional modules, including sample loading, sample pooling, nucleic acid extraction, PCR setup, reagent storage and a reserved PCR amplification module.
Paired with Tianlong's Gentier 96 Real-time PCR System, it delivers a true “sample-in, result-out” workflow. Specifically designed for blood screening applications, Aurora PANA X6 offers an integrated and automation-driven approach to nucleic acid testing.
576 samples/run, finish 2 runs within 9h40min; Directly pooling without collection tubes; Independent modules for each steps, ensure continuous workflow without interruption.
Integrated pooling module, together with powerful software, enabling performing single&pooling test in one run, ease experiment planning.
Integrated with original sample tube loading, 360°barcode scanning, capping&decapping function, simplify operation and minimize on-hand time.
1)Independent zoning; 2)Directional airflow; 3)UV disinfection; 4)HEPA filtration; 5)Anti-drip design; 6)Negative pressure; 7)Rotary mixing extraction to reduce aerosols
Throughput
576 (96×6 racks)
Certificate
CE;CB
Sample Types
Plasma, serum, whole blood, swab eluate, etc.
Pipetting Range
5 µL – 1000 µL
Pipette Channels
8 (4 per module), individually operated
Extraction Module
2 × 16T
PCR Module
2 × 48T (Gentier96 × 2)
Liquid Level Detection
Capacitance & pressure sensing technology
Extraction Temperature Control Range
Range from 30°C to 120°C for lysis and elution
Reagent Storage
4°C – 8°C refrigerated zone
Interface
18-inch touchscreen
Connectivity
Ethernet (TCP/IP), USB 2.0
Language
English, Chinese
Dimensions
1000 mm(L) × 870 mm(W) × 1780 mm (H)(Pooling module)
1000 mm(L) x 870 mm(W) x 1780 mm (H)(Purification Module)
Weight
332 kg (Pooling Module) 370 kg (Purification Module)
Power Supply
AC110V-240V, 50Hz, 1900 VA
