• Ultra-high throughput and rapid extraction: Npex 192 automatic nucleic acid extraction system can complete nucleic acid extraction of 192 samples in 12 min. Realizing high-throughput processing of parallel samples and providing high-quality nucleic acids for your downstream applications.
• Compact in design and space-saving: With 8-unit deep-well plate layout and Z-axis mechanical motion, Npex 192 can realize rapid extraction DNA and RNA extraction automation with the shortest movement. It can meet your high-throughput needs but also save your lab space.
• Easy to operate and visual monitoring:

1. 7-inch full-color LCD screen for easy operation
2. Integrated scanner for automatic protocol recognition
3. Real-time visual monitoring of the extraction progress

• Efficient temperature control:

1. Separate temperature settings for lysis and elution
2. Precise range from room temperature to 120°C

Throughput

1 ~ 192

Certificate

CE; CB

Processing Volume

30~1000μl

Compatible Consumables

96 deep-well-plate (1 ml reaction volume);

Vertical mixing sleeve

Magnetic Bead Residue

≤ 1%

Temperature Control Range

Temperature control separately for lysis and elution.

Temperature ranges from room temperature to 120°C.

Vertical Mixing

8 gears adjustable

Operating Language

Built-in bilingual (Chinese and English) operating languages.

Operation Mode

7-inch color LCD touch screen operation

Protocol Management

Flexible to create, edit and delete protocols

QR Code Scanning

With built-in barcode scanner, automatic scanning, identification and running protocols

Operation Monitoring

Visual monitoring of nucleic acid extraction progress

Program Storage

> 1000 programs can be stored

Contamination Control

1) Negative-pressure HEPA filtration;

2) UV disinfection ;

3) Anti-dripping design

Auto Power-off

Auto power-off after UV disinfection

Power failure protection

Choose freely whether or not to continue the experiment when the power is on again after cutting off

Connection Port Type

USB port

Network Connection

Ethernet port for remote control

Dimensions

710 mm×535 mm×515 mm (L×W×H)

Weight

55 kg

Power Supply

AC 100-240V, 50/60Hz
