Throughput: Performs up to 160 tests per hour

Tray Capacity: 40 sample positions, 36 reagent positions, 60 cuvettes

Dual Probes: Separate sample and reagent probes with mixer

Contamination Control: Isolated air flow and washing stations

Optical System: Multi-wavelength detection (8 wavelengths, 340–670 nm)

Dilution Handling: Programmable pre-dilution and auto-dilution functions

Quality Control: L-J plot, Westgard rules, multipoint calibration

Water Efficiency: Low water consumption of just 2.5 L/hour

Throughput: 160 tests/hour

Assay Methods: Endpoint, kinetic, fixed time, bichromatic/monochromatic

Measuring Principles: Absorbance photometry, immunoturbidimetry

Sample Volume: 1–100 µL (step 0.1 µL)

Reagent Volume: 1–400 µL

Reaction Volume: 200–300 µL

Onboard Cooling: ≤15°C for reagents

Wavelengths: 8 filters (340–670 nm)

Absorbance Range: 0–3.5 Abs

Calibration: Linear, non-linear, multipoint, K-factor

QC Tools: L-J plot, Westgard rules

Water Consumption: 2.5 L/hour

Lamp: Halogen
